Relay Tester

Relay Tester
Relay Tester
Send Inquiry
Product Code : SPM17
Brand Name : Parametric
Price And Quantity
  • Minimum Order Quantity
  • 1 Unit
  • Price
  • 67000 INR/Unit
Product Specifications
  • Material
  • Aluminium
  • Computerized
  • Yes
  • Automatic Grade
  • Automatic
  • Voltage
  • 220V AC Volt (v)
  • Power
  • 220 Watt (w)
  • Dimension (L*W*H)
  • 250 x 320 x 275 Millimeter (mm)
  • Color
  • White
Product Description
We are renowned manufacturers and suppliers of Relay performance tester.

PRC offers Microcontroller based programmable test equipment used to test all types of Auto Relay for Pull in & Dropout voltage. This is offered in two modules;

1. Control Module Relay Tester:
This includes Microcontroller unit with LCD/LED and Key pad for easy user interface to do the programming of Test Parameters.

2. Power Supply Module for Relay:
Output the various supply voltages as per input by control unit. Monitoring terminals for Voltage and Current are provided on front panel.

Mode of Operation:
PRC Relay Test System has three modes of operations as below;

Calibration Mode:
Power supply output voltage is calibrated in this mode (Calibrated at works)

Test Mode:

In this mode, first Program mode is fetched. After Programming the parameters, LCD/LED shows TEST MODE. When TEST request switch is pressed, supply voltage across the relay coil is increases till the relay is operated. When relay is operated, Pull in voltage is displayed on LCD/LED. Voltage increases till it reaches to maximum test voltage, then voltage start decreasing till relay contact is dropped and drop out voltage is displayed on LCD/LED.

Program Mode:

Following parameters can be programmed in this mode;
Type of Relay: CO or NO
Maximum Pull-in-Voltage
Minimum Pull-in-Voltage
Maximum Drop-out Voltage
Minimum Drop-out Voltage
Maximum Coil Test Voltage

Salient features:
  • Automatic Tester to Test PULL-IN & DRP-OUT for electromagnetic Relay
  • Facility to preset Go/No,
  • Go Limits for Max, Min PULL-IN & Max, Min DROP-OUT
  • 16 X 2 LCD Alphanumeric display to indicate test parameters & test results
  • LED Indication for PASS/FAIL External test Pass signal for Punching
  • Protection against short circuit
  • Rugged & robust design to suit Indian Industrial environment
  • Easy handling & User friendly
  • Dependable & heavy duty performance
